Parameter | CYTJ45 |
---|---|
Overall dimensions (length * width * height) | 11354*2060*2525/3225mm |
Applicable section of anchor rod (b * h) | 6645mm*6060mm |
Drilling diameter | φ43mm-φ89mm |
Drill pipe length | 3700/4305mm |
Drill hole depth | 3315/3920mm |
Motor power | 55kw |
Hydraulic oil tank capacity | 180L |
Overall weight | 13500kg |
Drilling arm | |
Rotation | Positive 180°/Negative 180° |
Propulsion downward/upward | 3°/90° |
Compensation | 1500mm |
Chassis | |
Maximum power of diesel engine | 80HP/60kw |
Turning direction | ±38° |
Tire specifications | 9.0*R20 |
Climbing ability | ≤24% |
Rear axle swing angle | ±7° |
Approach angle/departure angle | 18°/15° |
Walking speed | 10 km/h |
Minimum turning radius | Inside 5.5m/Outside7m |
Minimum ground clearance | 265mm |
Driving brake | wet brake |
Fuel tank | 80L |
Electrical system | |
Voltage | 380v |
Battery | 2*12v |
Driving light | 24v |
Work light | 220v |
Gas supply system | |
Flow rate | 0.35m³/min |
Working air pressure | 0.3~0.7Mpa |
Water supply system | |
Flow rate | 70L/min |
Working water pressure | 0.8~1.2Mpa |
